What is a Transformer?
Transformer is a neural network architecture that has fundamentally changed the approach to Artificial Intelligence. Transformer was first introduced in the seminal paper "Attention is All You Need" in 2017 and has since become the go-to architecture for deep learning models, powering text-generative models like OpenAI's GPT, Meta's Llama, and Google's Gemini. Beyond text, Transformer is also applied in audio generation, image recognition, protein structure prediction, and even game playing, demonstrating its versatility across numerous domains.
Fundamentally, text-generative Transformer models operate on the principle of next-word prediction: given a text prompt from the user, what is the most probable next word that will follow this input? The core innovation and power of Transformers lie in their use of self-attention mechanism, which allows them to process entire sequences and capture long-range dependencies more effectively than previous architectures.
GPT-2 family of models are prominent examples of text-generative Transformers. Transformer Explainer is powered by the GPT-2 (small) model which has 124 million parameters. While it is not the latest or most powerful Transformer model, it shares many of the same architectural components and principles found in the current state-of-the-art models making it an ideal starting point for understanding the basics.
Transformer Architecture
Every text-generative Transformer consists of these three key components:
- Embedding: Text input is divided into smaller units called tokens, which can be words or subwords. These tokens are converted into numerical vectors called embeddings, which capture the semantic meaning of words.
- Transformer Block is the fundamental building block of
the model that processes and transforms the input data. Each block includes:
- Attention Mechanism, the core component of the Transformer block. It allows tokens to communicate with other tokens, capturing contextual information and relationships between words.
- MLP (Multilayer Perceptron) Layer, a feed-forward network that operates on each token independently. While the goal of the attention layer is to route information between tokens, the goal of the MLP is to refine each token's representation.
- Output Probabilities: The final linear and softmax layers transform the processed embeddings into probabilities, enabling the model to make predictions about the next token in a sequence.
Embedding
Let's say you want to generate text using a Transformer model. You add the prompt like this
one: “Data visualization empowers users to”. This input needs to be converted
into a format that the model can understand and process. That is where embedding comes in:
it transforms the text into a numerical representation that the model can work with. To
convert a prompt into embedding, we need to 1) tokenize the input, 2) obtain token
embeddings, 3) add positional information, and finally 4) add up token and position
encodings to get the final embedding. Let’s see how each of these steps is done.
Step 1: Tokenization
Tokenization is the process of breaking down the input text into smaller, more manageable
pieces called tokens. These tokens can be a word or a subword. The words "Data"
and "visualization" correspond to unique tokens, while the word
"empowers"
is split into two tokens. The full vocabulary of tokens is decided before training the model:
GPT-2's vocabulary has 50,257 unique tokens. Now that we split our input text
into tokens with distinct IDs, we can obtain their vector representation from embeddings.
Step 2. Token Embedding
GPT-2 Small represents each token in the vocabulary as a 768-dimensional vector; the
dimension of the vector depends on the model. These embedding vectors are stored in a
matrix of shape (50,257, 768), containing approximately 39 million
parameters! This extensive matrix allows the model to assign semantic meaning to each
token.
Step 3. Positional Encoding
The Embedding layer also encodes information about each token's position in the input prompt. Different models use various methods for positional encoding. GPT-2 trains its own positional encoding matrix from scratch, integrating it directly into the training process.
Step 4. Final Embedding
Finally, we sum the token and positional encodings to get the final embedding representation. This combined representation captures both the semantic meaning of the tokens and their position in the input sequence.
Transformer Block
The core of the Transformer's processing lies in the Transformer block, which comprises multi-head self-attention and a Multi-Layer Perceptron layer. Most models consist of multiple such blocks that are stacked sequentially one after the other. The token representations evolve through layers, from the first block to the 12th one, allowing the model to build up an intricate understanding of each token. This layered approach leads to higher-order representations of the input.
Multi-Head Self-Attention
The self-attention mechanism enables the model to focus on relevant parts of the input sequence, allowing it to capture complex relationships and dependencies within the data. Let’s look at how this self-attention is computed step-by-step.
Step 1: Query, Key, and Value Matrices
Each token's embedding vector is transformed into three vectors: Query (Q), Key (K), and Value (V). These vectors are derived by multiplying the input embedding matrix with learned weight matrices for Q, K, and V. Here's a web search analogy to help us build some intuition behind these matrices:
- Query (Q) is the search text you type in the search engine bar. This is the token you want to "find more information about".
- Key (K) is the title of each web page in the search result window. It represents the possible tokens the query can attend to.
- Value (V) is the actual content of web pages shown. Once we matched the appropriate search term (Query) with the relevant results (Key), we want to get the content (Value) of the most relevant pages.
By using these QKV values, the model can calculate attention scores, which determine how much focus each token should receive when generating predictions.
Step 2: Masked Self-Attention
Masked self-attention allows the model to generate sequences by focusing on relevant parts of the input while preventing access to future tokens.
- Attention Score: The dot product of Query and Key matrices determines the alignment of each query with each key, producing a square matrix that reflects the relationship between all input tokens.
- Masking: A mask is applied to the upper triangle of the attention matrix to prevent the model from accessing future tokens, setting these values to negative infinity. The model needs to learn how to predict the next token without “peeking” into the future.
- Softmax: After masking, the attention score is converted into probability by the softmax operation which takes the exponent of each attention score. Each row of the matrix sums up to one and indicates the relevance of every other token to the left of it.
Step 3: Output
The model uses the masked self-attention scores and multiplies them with the
Value matrix to get the
final output
of the self-attention mechanism. GPT-2 has 12 self-attention heads, each capturing
different relationships between tokens. The outputs of these heads are concatenated and passed
through a linear projection.
MLP: Multi-Layer Perceptron
After the multiple heads of self-attention capture the diverse relationships between the
input tokens, the concatenated outputs are passed through the Multilayer Perceptron
(MLP) layer to enhance the model's representational capacity. The MLP block consists of
two linear transformations with a GELU activation function in between. The first linear
transformation increases the dimensionality of the input four-fold from 768
to 3072. The second linear transformation reduces the dimensionality back
to the original size of 768, ensuring that the subsequent layers receive
inputs of consistent dimensions. Unlike the self-attention mechanism, the MLP processes
tokens independently and simply map them from one representation to another.
Output Probabilities
After the input has been processed through all Transformer blocks, the output is passed
through the final linear layer to prepare it for token prediction. This layer projects
the final representations into a 50,257
dimensional space, where every token in the vocabulary has a corresponding value called
logit. Any token can be the next word, so this process allows us to simply
rank these tokens by their likelihood of being that next word. We then apply the softmax
function to convert the logits into a probability distribution that sums to one. This
will allow us to sample the next token based on its likelihood.
The final step is to generate the next token by sampling from this distribution The temperature
hyperparameter plays a critical role in this process. Mathematically speaking, it is a very
simple operation: model output logits are simply divided by the
temperature:
temperature = 1: Dividing logits by one has no effect on the softmax outputs.temperature < 1: Lower temperature makes the model more confident and deterministic by sharpening the probability distribution, leading to more predictable outputs.temperature > 1: Higher temperature creates a softer probability distribution, allowing for more randomness in the generated text – what some refer to as model “creativity”.
Adjust the temperature and see how you can balance between deterministic and diverse outputs!
Advanced Architectural Features
There are several advanced architectural features that enhance the performance of Transformer models. While important for the model's overall performance, they are not as important for understanding the core concepts of the architecture. Layer Normalization, Dropout, and Residual Connections are crucial components in Transformer models, particularly during the training phase. Layer Normalization stabilizes training and helps the model converge faster. Dropout prevents overfitting by randomly deactivating neurons. Residual Connections allows gradients to flow directly through the network and helps to prevent the vanishing gradient problem.
Layer Normalization
Layer Normalization helps to stabilize the training process and improves convergence. It works by normalizing the inputs across the features, ensuring that the mean and variance of the activations are consistent. This normalization helps mitigate issues related to internal covariate shift, allowing the model to learn more effectively and reducing the sensitivity to the initial weights. Layer Normalization is applied twice in each Transformer block, once before the self-attention mechanism and once before the MLP layer.
Dropout
Dropout is a regularization technique used to prevent overfitting in neural networks by randomly setting a fraction of model weights to zero during training. This encourages the model to learn more robust features and reduces dependency on specific neurons, helping the network generalize better to new, unseen data. During model inference, dropout is deactivated. This essentially means that we are using an ensemble of the trained subnetworks, which leads to a better model performance.
Residual Connections
Residual connections were first introduced in the ResNet model in 2015. This architectural innovation revolutionized deep learning by enabling the training of very deep neural networks. Essentially, residual connections are shortcuts that bypass one or more layers, adding the input of a layer to its output. This helps mitigate the vanishing gradient problem, making it easier to train deep networks with multiple Transformer blocks stacked on top of each other. In GPT-2, residual connections are used twice within each Transformer block: once before the MLP and once after, ensuring that gradients flow more easily, and earlier layers receive sufficient updates during backpropagation.
Interactive Features
Allows you to explore the inner workings of the Transformer. Here are some of the interactive features you can play with:
- Input your own text sequence to see how the model processes it and predicts the next word. Explore attention weights, intermediate computations, and see how the final output probabilities are calculated.
- Use the temperature slider to control the randomness of the model’s predictions. Explore how you can make the model output more deterministic or more creative by changing the temperature value.
- Interact with attention maps to see how the model focuses on different tokens in the input sequence. Hover over tokens to highlight their attention weights and explore how the model captures context and relationships between words.
